Automatic Vertical High Speed Zxx

Basic Info.

Model NO.	Zxx-C1812
Glass Thickness	3-19mm
Power	9.6kw
Volt.	380V/50Hz
Speed	0-12m/Min
Heads Number	2
Max.Motion Range	1800*1200
Drawing	CAD Drawing
Processing Precision	0.01mm
Fuction	Drilling Milling Grinding Polishin Engraving
Min Process Size	75X15mm
After-Service	Provides 24 Hours Online Services
Advantage	Four Functions in One Together
Delivery	25days
Application	Glass Cabinet Table, Glass Sinks, Shower Door ....
Transport Package	Standard Export Package
Specification	1850*2600*2200
Trademark	znxu
Origin	China
HS Code	8464901900
Production Capacity	50 Sets Per Month

Product Description

Product parameters

Description	unit	parameter
Model No.		ZXX - C1812
Colum	Set	Heavy iron
		China
Control System	set	Leetro
Axis	PC	Cutter change : by hand
		Diam:¢125
		coller:cool water
		RPM:42000 RPM 2800
		POWER:1.5KW 4.5KW
Drive	set	YMPC
Invertor	kw	BEST : 11KW
Work table size	mm	1800*1200MM
Max Process Glass	mm	1400*1000mm
Z-axis space height-open	mm	380
motor	set	China
Internal of machine structure	set	Half cover/ waterproof design
Work table load weight	KG	120
Positioning accuracy	mm	0.01
Repeated positioning accuracy	mm	0.01
Cutting speed	M/MIN	0-2M/MIN
Grinder speed	M/MIN	0-12M/MIN
Stroke protection	PC	Omron,Japan
GEAR	PC	GERMAN DMJ-1.5M High precision
Limit switch		CHIIB
Guide Screw bearing	PC	HIWIN
		Model: Z axis with diagonal contact
Lubrication system	set	Origin :
		Lubrication automatically
Cooling type	set	Water pump
Main axis cooling	set	Automatic thermostat cooler
Main electric		CHNT/Schneider
Volt./Frequecny	KW	AC/380v/10KW/50HZ (AS PER CUSTOMER REQUEST)
Machine Size	mm	1900x2700x2300mm
weight	KG	1600
power	KW.H	11.1
